Rear View - White Background
  • Rough Terrain Forklifts
  • HEAVY DUTY

T30C – 3 Ton Ultra-Compact Rough Terrain Forklift | LT FORKLIFT

T30C

Ultra-compact turning radius for tight spaces
Minimal ground clearance for stability
Full 3-ton lifting capacity in compact design
Excellent maneuverability
Durable integrated axle bridge
Reliable Yunnei engine
Load Capacity

3,000 kg

Lift Height

3000 mm

Power

Diesel

Drive

4WD

Get a Quote
Download PDF

Full Specifications

The T30C is an ultra-compact 3-ton rough terrain forklift engineered for maximum maneuverability in tight spaces. With an exceptional 1500mm turning radius and compact 3700mm length, the T30C is ideal for congested construction sites, warehouses, and confined work areas.

Load Capacity：3,000 kg
Standard Lift Height：3000 mm
Max Lift Height：3000 mm
Engine Model：Yunnei 490
Engine Power：37 KW
Battery Specs：N/A
Transmission：265 Dual-Speed High-Low Pump Torque Converter
Max Speed (Loaded)：N/A
Max Speed (Unloaded)：N/A
Gradeability：≤38°
Min Turning Radius：1500 mm
Overall Dimensions (L)：3700 mm
Overall Dimensions (W)：1800 mm
Overall Dimensions (H)：2300 mm
Self Weight：N/A
Fork Length：1220 mm
Ground Clearance：180 mm
Front Tire：20.5/70-16
Rear Tire：20.5/70-16
Mast Tilt Angle：10°/-6°
Fuel/Battery Capacity：N/A

Product Highlights

Exceptional Turning Radius

1500mm turning radius enables operation in extremely confined spaces, reducing repositioning time and improving efficiency.

Minimal Ground Clearance

180mm ground clearance provides excellent stability while navigating uneven terrain and obstacles.

Compact Dimensions

3700mm length and 2300mm height fit in tight spaces while maintaining full lifting capacity.

Superior Maneuverability

Integrated one-piece axle bridge combined with tight turning radius delivers unmatched agility.
