K2-3.5T Diesel Premium Forklift - Rear Profile View
  • Balanced Forklifts
  • HEAVY DUTY

K2-3.5T Diesel Premium – 3.5 Ton Premium Diesel Balanced Forklift | LT FORKLIFT

K2-3.5T Diesel Premium

Premium Xinchai 4D29V41 engine
70L fuel tank for extended operation
Premium Heli-brand mast
Optional 5-meter lifting height
Advanced diesel performance
Excellent reliability
Load Capacity

3,500 kg

Lift Height

3000 mm

Power

Diesel

Drive

2WD

Get a Quote
Download PDF

Full Specifications

The K2-3.5T Diesel Premium is a 3.5-ton premium diesel balanced forklift featuring Xinchai 4D29V41 engine (36.8KW), 70L fuel tank, and premium specifications. With optional 5-meter lifting height and advanced diesel performance, the K2-3.5T Diesel Premium is engineered for demanding outdoor and industrial operations.

Load Capacity：3,500 kg
Standard Lift Height：3000 mm
Max Lift Height：5000 mm
Engine Model：Xinchai 4D29V41
Engine Power：36.8 KW
Battery Specs：N/A
Transmission：Mechanical
Max Speed (Loaded)：18 km/h
Max Speed (Unloaded)：20 km/h
Gradeability：15% (Empty) / 13% (Loaded)
Min Turning Radius：2400 mm
Overall Dimensions (L)：2850 mm
Overall Dimensions (W)：1250 mm
Overall Dimensions (H)：2350 mm
Self Weight：4500 kg
Fork Length：1220 mm
Ground Clearance：135 mm
Front Tire：28×9-15
Rear Tire：650-10
Mast Tilt Angle：6°/-12°
Fuel/Battery Capacity：70L Diesel

Product Highlights

Xinchai 4D29V41 Engine

Premium Xinchai 4D29V41 engine (36.8KW) provides exceptional power and reliability for demanding operations.

70L Fuel Tank

Large 70L fuel tank enables extended operation without frequent refueling.

70L Fuel Tank

Premium Heli-brand mast and advanced hydraulic system ensure superior performance.

Optional 5-Meter Lifting

Standard 3-meter lifting height with optional three-section mast for 5-meter maximum height.

Gallery & Video

Product Main Image
1 / 0

Compact 3.5T Rough Terrain Forklift | Ultimate Tight Space Solution

Are standard off-road forklifts too bulky for your facility? Watch the LT FORKLIFT 3.5T Integral All-Terrain Forklift easily navigate tight spaces and narrow aisles! Engineered for proactive excellence, its unique integrated body design significantly reduces the turning radius without sacrificing heavy-duty performance. Perfect for crowded lumber yards, construction sites, and indoor/outdoor transitional operations. Quick Specs: Model: 3.5T Integral All-Terrain Forklift Rated Lifting Weight: 3500 Kg Drive Mode: True 4-Wheel Drive (4WD) Full hydraulic power steering Rough Terrain Forklift, Compact Forklift, Narrow Aisle Forklift, 4×4 Forklift, LT Forklift, 3.5 Ton Forklift, Material Handling Equipment, Forklift Manufacturer China, Off-Road Forklift, Lumber Yard Equipment
