K2-2.5T – 2.5 Ton Compact Electric Balanced Forklift | LT FORKLIFT

K2-2.5T

Compact 5000W motor
120A lithium battery
Compact dimensions for tight spaces
Optional 6-meter lifting
Excellent maneuverability
Perfect for small operations
Load Capacity

2,500 kg

Lift Height

3000 mm

Power

Electric (Li-ion)

Drive

2WD

Get a Quote
Download PDF

Full Specifications

The K2-2.5T is a 2.5-ton compact electric balanced forklift featuring 5000W drive motor, 5000W lifting motor, and 120A lithium battery. With compact dimensions, optional 6-meter lifting height, and excellent maneuverability, the K2-2.5T is ideal for small warehouses and confined spaces.

Load Capacity：2,500 kg
Standard Lift Height：3000 mm
Max Lift Height： 6000 mm
Engine Model：N/A
Engine Power：N/A
Battery Specs：120A Lithium, 60-72V
Transmission：Electric
Max Speed (Loaded)：12 km/h
Max Speed (Unloaded)：13 km/h
Gradeability：15% (Empty) / 13% (Loaded)
Min Turning Radius：2300 mm
Overall Dimensions (L)：2500 mm
Overall Dimensions (W)：1190 mm
Overall Dimensions (H)：2150 mm
Self Weight： 2700 kg
Fork Length：1070 mm
Ground Clearance：120 mm
Front Tire：650-10
Rear Tire： 500-8
Mast Tilt Angle： 6°/-12°
Fuel/Battery Capacity：120A Lithium

Product Highlights

5000W Compact Motor

Efficient 5000W motor provides smooth performance in compact design.

120A Lithium Battery

Compact 120A lithium battery delivers extended runtime for continuous operations.

Compact Dimensions

2500mm length and 1190mm width fit in tight spaces and narrow aisles.

Optional 6-Meter Lifting

Standard 3-meter lifting height with optional three-section mast for 6-meter maximum height.
